Creating a Similarity Plot

This example assumes you have a local GPU with Ollama or you can get access to a service that creates embeddings.

Intall and Test Ollama

Install Ollama

I have a list of 100 questions frequently asked in an
undergraduate course on circuits. I want to create a
2-D plot that groups similar questions by creating
embeddings for each question. I also have access to a
GPU that is running ollama and has the llama 3.2 model
available. Can you suggest a Python program that will
take the input file of questions separated by newlines
and outputs a 2D plot grouping similar questions together?

Test Ollama Embeddings Service

$ curl http://localhost:11434/api/embeddings -d '{
>   "model": "mxbai-embed-large",
>   "prompt": "Llamas are members of the camelid family"
> }'
{"embedding":[0.5827146172523499,1.1744482517242432...

Response

Note

I have update the response to include some links.

ChatGPT o1-min Thought for 4 seconds

Certainly! Below is a Python program that reads a list of questions from a text file, generates embeddings for each question using the Llama 3.2 model via Ollama, reduces the dimensionality of these embeddings to 2D using UMAP, and finally plots the questions on a 2D scatter plot where similar questions are grouped together.

Prerequisites

1. Ollama Setup:

   • Ensure that Ollama is installed and running on your GPU machine.
   • Verify that the Llama 3.2 model is available and configured to generate embeddings.
   • Make sure the ollama command-line tool is accessible from your environment.

   • Python Libraries:

   • Install the required Python libraries using pip:

pip install matplotlib seaborn umap-learn

Python Program

import subprocess
import json
import time
import sys
import os
from typing import List
import umap
import matplotlib.pyplot as plt
import seaborn as sns

def read_questions(file_path: str) -> List[str]:
    """
    Reads questions from a file, each separated by a newline.
    """
    if not os.path.isfile(file_path):
        print(f"Error: File '{file_path}' does not exist.")
        sys.exit(1)

    with open(file_path, 'r', encoding='utf-8') as file:
        questions = [line.strip() for line in file if line.strip()]
    return questions

def get_embedding(question: str) -> List[float]:
    """
    Gets the embedding for a single question using Ollama's CLI.
    """
    try:
        # Call the Ollama CLI to get the embedding
        result = subprocess.run(
            ['ollama', 'embeddings', 'llama-3.2', question],
            capture_output=True,
            text=True,
            check=True
        )
        # Parse the JSON output
        output = json.loads(result.stdout)
        embedding = output.get('embedding')
        if embedding is None:
            print(f"Warning: No embedding found for question: {question}")
            return []
        return embedding
    except subprocess.CalledProcessError as e:
        print(f"Error generating embedding for question: {question}")
        print(e.stderr)
        return []
    except json.JSONDecodeError:
        print(f"Error decoding JSON for question: {question}")
        return []

def generate_embeddings(questions: List[str]) -> List[List[float]]:
    """
    Generates embeddings for a list of questions.
    """
    embeddings = []
    for idx, question in enumerate(questions, 1):
        print(f"Processing ({idx}/{len(questions)}): {question}")
        embedding = get_embedding(question)
        if embedding:
            embeddings.append(embedding)
        else:
            # Handle missing embeddings by appending a zero vector
            embedding_size = 768  # Assuming Llama's embedding size
            embeddings.append([0.0] * embedding_size)
        # Optional: Add a small delay to avoid overwhelming the CLI
        time.sleep(0.1)
    return embeddings

def reduce_dimensions(embeddings: List[List[float]]) -> List[List[float]]:
    """
    Reduces high-dimensional embeddings to 2D using UMAP.
    """
    reducer = umap.UMAP(n_neighbors=15, min_dist=0.1, metric='cosine', random_state=42)
    reduced = reducer.fit_transform(embeddings)
    return reduced.tolist()

def plot_embeddings(reduced_embeddings: List[List[float]], questions: List[str], output_file: str = "questions_plot.png"):
    """
    Plots the 2D embeddings with annotations.
    """
    plt.figure(figsize=(12, 8))
    sns.set(style="whitegrid")

    x = [point[0] for point in reduced_embeddings]
    y = [point[1] for point in reduced_embeddings]

    plt.scatter(x, y, s=100, color='skyblue', edgecolor='k')

    for i, question in enumerate(questions):
        plt.text(x[i]+0.5, y[i]+0.5, str(i+1), fontsize=9)

    plt.title("2D Visualization of Circuit Questions Embeddings", fontsize=16)
    plt.xlabel("UMAP Dimension 1")
    plt.ylabel("UMAP Dimension 2")
    plt.tight_layout()
    plt.savefig(output_file, dpi=300)
    plt.show()
    print(f"Plot saved as {output_file}")

def main():
    # Path to the input file containing questions
    input_file = "questions.txt"  # Replace with your file path

    # Step 1: Read questions from the file
    questions = read_questions(input_file)
    if not questions:
        print("No questions found in the input file.")
        sys.exit(1)
    print(f"Total questions loaded: {len(questions)}")

    # Step 2: Generate embeddings for each question
    print("Generating embeddings...")
    embeddings = generate_embeddings(questions)
    print("Embeddings generation completed.")

    # Step 3: Reduce embeddings to 2D
    print("Reducing dimensions...")
    reduced_embeddings = reduce_dimensions(embeddings)
    print("Dimensionality reduction completed.")

    # Step 4: Plot the embeddings
    print("Plotting embeddings...")
    plot_embeddings(reduced_embeddings, questions)

if __name__ == "__main__":
    main()

Explanation of the Code

1. Reading Questions:

2. The read_questions function reads the input file (questions.txt by default) and loads each question into a list after stripping any leading/trailing whitespace.

3. It also checks if the file exists and exits gracefully with an error message if not.

4. Generating Embeddings:

5. The get_embedding function uses Python's subprocess module to call the ollama CLI and generate an embedding for a single question.

6. It assumes that the command ollama embeddings llama-3.2 "question" returns a JSON object with an embedding field containing the embedding vector.
7. Error handling is included to catch issues with the subprocess call or JSON parsing.

8. The generate_embeddings function iterates over all questions, generates their embeddings, and collects them into a list. It also adds a small delay (time.sleep(0.1)) between calls to prevent overwhelming the CLI.

9. Dimensionality Reduction:

10. The reduce_dimensions function uses UMAP (Uniform Manifold Approximation and Projection) to reduce the high-dimensional embeddings to 2D.

11. UMAP is chosen for its efficiency and ability to preserve the global structure of the data. You can also use t-SNE or PCA if preferred.

12. Plotting:

13. The plot_embeddings function creates a scatter plot using Matplotlib and Seaborn.

14. Each point represents a question, and they are annotated with their respective indices for easy reference.

15. The plot is saved as questions_plot.png and also displayed.

16. Main Execution Flow:

17. The main function orchestrates the entire process: reading questions, generating embeddings, reducing dimensions, and plotting.

18. It specifies the input file (questions.txt), which you should replace with the path to your actual file containing the 100 questions.

Usage Instructions

1. Prepare the Input File:

2. Create a text file named questions.txt (or any name you prefer) with each question on a separate line. For example:

Sample questions.txt file:

What is Ohm's Law?
Explain Kirchhoff's Voltage Law.
How does a capacitor work in a circuit?

• If your input file has a different name or path, update the input_file variable in the main function accordingly.

• Test your Ollama configuration

• Run the Plot Questions Script:

• Save the Python script to a file, for example, plot_questions.py.

• Open a terminal and navigate to the directory containing plot_questions.py.

• Execute the script:

python plot_questions.py

1. View the Plot:

   • After running, the script will display a 2D plot showing the grouping of similar questions.
   • The plot will also be saved as questions_plot.png in the same directory.

Notes and Tips

• Embedding Size: The script assumes that the embedding size from Llama 3.2 is 768 dimensions. If it's different, adjust the embedding_size variable accordingly.

• Error Handling: The script includes basic error handling for missing files, subprocess errors, and JSON decoding issues. Ensure that Ollama is correctly set up and the ollama CLI is functioning as expected.

• Performance: For 100 questions, the script should run relatively quickly. If you plan to scale this up, consider optimizing the embedding generation process, possibly by batching requests if Ollama supports it.

• Visualization Enhancements: You can enhance the plot by adding colors based on clusters, interactive tooltips, or integrating with libraries like Plotly for interactive visualizations.

• Caching Embeddings: To save time on subsequent runs, especially if the questions don't change, consider caching the embeddings to a file (e.g., JSON or pickle) and loading them instead of regenerating.

I hope this helps you effectively visualize and group similar circuit questions! If you encounter any issues or have further questions, feel free to ask.
