Lab 11: A Countdown Timer

A countdown timer going from 00:05 to 00:00 in red digits while the ring of cyan ticks empties, then flashing "TIME'S UP!"

A countdown timer counts down to zero, then sounds an alarm. It's great for cooking, homework breaks, or board games. Set the minutes and seconds with the buttons, press start, and watch the ring around the edge empty as time runs out.

What You Will Learn

  • how to set a number with buttons
  • what a state machine is (every video game uses them!)
  • how a program can count down without drifting

Run It

Open 11-countdown-timer.py in Thonny and click Run. It starts at 5:00. To change it:

  1. Press MODE. The minutes turn yellow.
  2. Press UP or DOWN to change them. Hold a button to go faster.
  3. Press MODE. Now the seconds are yellow. Change them too.
  4. Press MODE once more when you're done.
  5. Press UP to start!

Setting the timer: the seconds are highlighted in yellow and the screen says SET SECONDS

While it counts down, UP pauses it and UP again keeps going. While it's paused, DOWN resets it back to the time you set. For the last 10 seconds the numbers turn red. At zero, the screen flashes 00:00 and TIME'S UP! in red, and the Pico's little green light flashes too, until you press any button.

What Is a State Machine?

Here's a puzzle: what does the UP button do? It depends!

  • While you're setting the time, UP adds one.
  • When the timer is ready, UP starts it.
  • While it's running, UP pauses it.

The timer is always in exactly one state, and the state decides what each button does. The program keeps the current state in one variable, state, and every time a button is pressed it asks, "What state am I in right now?" Here are all six states, with arrows showing which button moves the timer from one state to the next:

stateDiagram-v2
    direction LR
    state "Set minutes" as SM
    state "Set seconds" as SS
    state "Ready" as R
    state "Running" as RUN
    state "Paused" as P
    state "Time is up!" as D
    [*] --> R
    R --> SM: MODE
    SM --> SS: MODE
    SS --> R: MODE
    R --> RUN: UP
    RUN --> P: UP
    P --> RUN: UP
    P --> R: DOWN
    RUN --> D: reaches 00:00
    D --> R: any button

This picture is called a state diagram. Video games use state machines all the time: a character might be standing, running, jumping, or falling, and pressing the jump button only works in some of those states.

Counting Down Without Drifting

Like the stopwatch, the timer doesn't subtract a little each time around its loop. When you press start, it works out the exact moment the timer will end. Then, whenever it needs to, it checks how far away that moment is:

1
2
end_ticks = time.ticks_add(now, remaining_ms)     # when you press start
remaining_ms = time.ticks_diff(end_ticks, now)    # every time it checks

The Shrinking Ring

The ring of 60 ticks shows how much time is left. At the start, all 60 are lit. When half the time is gone, only 30 are lit. Only the one tick that goes dark gets redrawn, so the ring never flickers.

Add a buzzer

The alarm is silent unless you add a small piezo buzzer, a tiny speaker that beeps. Connect its + leg to a free pin, such as GP16, and its − leg to GND. Then open config.py and change BUZZER_PIN = None to BUZZER_PIN = 16. It will beep in time with the flashing.

Try This

  1. Set the timer for 10 seconds and watch the numbers turn red.
  2. Change START_MINUTES = 5 at the top of the program to the number of minutes you use most.
  3. Change WARNING_MS = 10_000 to 30_000. When do the numbers turn red now? (1,000 ms is one second.)
