Notes for Teachers

These notes are for teachers, parents, and anyone who wants the technical story behind the GC9B72 Smartwatch Kit: where the driver came from, how fast the hardware really is, and how each watch face keeps flicker to a minimum. The lab pages themselves are written for students around 11 years old.

About the pictures in these pages

Every screen picture in the lab pages was made by running that lab's real code in a desktop simulator of the GC9B72 display. The simulator decodes the same SPI commands the Pico sends to the panel, so the pictures show exactly the pixels the program draws. Every lab has also been run on a real Pico 2 W and GC9B72 panel.

The simulator is in the repository at src/display-simulators/gc9b72. After changing a lab, render_sw_gc9b72_docs.py regenerates all of these pictures, and checks/run_all.py re-runs the checks described on this page.

What the Probe Reports

01-probe.py checks everything software can check. Here is what it measured on our kit:

Check	Result
Board	Raspberry Pi Pico 2 W with RP2350, MicroPython 1.29.0, 150 MHz
RAM	436 KB of Python heap (of the chip's 520 KB)
Full frame buffer	A 360×360 RGB565 buffer (253 KB) fits
Flash	4 MB chip: 1.5 MB firmware, 2.5 MB filesystem
SPI	Asked for 24 MHz, got 24 MHz
Full-screen fill	131 ms, so at most about 8 full redraws per second

The flash chip size is not something MicroPython will tell you. The probe finds it with a trick: the flash chip ignores address bits it does not have, so on a 4 MB chip, reading 4 MB past the start "wraps around" and returns the same bytes as the start.

The Driver

GalaxyCore has never published a public datasheet for the GC9B72. The register start-up sequence in lib/gc9b72.py comes from the xboot project's fb-gc9b72.c, by way of the MaliosDark/Arduino_GC9B72 Arduino driver (MIT). It was translated to MicroPython for the robot-faces project, where it was first tested on real hardware. This kit uses that same file, unchanged.

The driver works like the GC9A01 driver in our other smartwatch kit:

There is no frame buffer and no show(). Every drawing call sends its pixels over SPI immediately.
There is no built-in font. text() takes a font module as its first argument: config.SMALL_FONT (8×16) or config.BIG_FONT (16×32).
There is no ellipse() or poly(). lib/shapes.py builds circles, rings, polygons, and triangles from the horizontal lines the driver can draw.

SPI speed

MicroPython makes the SPI clock by dividing a 48 MHz peripheral clock, and it rounds down to the nearest speed it can make. That gives 24 MHz or 12 MHz, with nothing in between and nothing above 24:

You ask for	You get
20,000,000	12,000,000
24,000,000	24,000,000
62,500,000	24,000,000

The kit runs at 24 MHz. If you see speckled pixels on long wires, change BAUDRATE in config.py to 12_000_000.

How the Watch Face Avoids Flicker

A full-screen fill takes 131 ms. Clearing and redrawing the whole face every second would make the screen flash. So 05-analog-watch-face.py draws the dial once and then, each second:

erases the old second hand by drawing it again in black
if the minute changed, erases the old minute and hour hands the same way
repairs whatever the erased second hand passed over
draws all three hands at their new angles

Step 3 stays small because of how the dial is laid out:

The ticks sit outside the tip of the longest hand, so no hand ever touches them.
The numerals sit outside the minute and hour hands, so only the second hand crosses them, and only the numeral nearest to it at that.
The hour and minute hands get redrawn every second anyway.

Measured on the real kit, drawing the dial takes 617 ms at start-up, and each second's update takes at most 232 ms (302 ms when the minute changes).

To check this layout, we ran the watch face against a simulated screen and compared every second's partial redraw, pixel by pixel, with a fresh drawing of the same time. They matched at every step, including noon, midnight, and large time jumps. Making the minute hand long enough to reach the numerals broke the match 208 times. Lab 05's comments suggest trying this yourself.

The Digital Watch Face

08-digital-watch-face.py shows the time in seven-segment digits 114 pixels tall, big enough to read across a room. The date sits below in the small font, and a ring of 60 ticks around the rim fills up as the seconds pass.

It follows one rule: only send the pixels that change.

Each digit is seven segments plus the six square joints where segments meet. A joint lights up whenever any segment touching it is lit, so each digit reads as one solid stroke. Each digit's pattern is stored as a number with one bit per piece, so old ^ new gives exactly the pieces that switched. Only those get repainted. Going from 12:59 to 1:00, a piece lit in both is never touched.
On a 12-hour clock the leftmost digit is only ever "1" or blank, so it is drawn as a narrow half digit (just the right-hand column), and the row is centered around it.
Unlit segments are painted a faint "ghost" color, like a real LCD watch. Turning a segment off means repainting it, never erasing it.
Each second lights one more tick on the ring.
The date is padded to a fixed width, and only characters that differ are repainted.

Run in a simulator with the real driver, every update sent exactly the pixels that changed and no others:

Update	Pixels sent	Time on the Pico 2 W
A normal second	333	8.5 ms
A new minute (10:31 to 10:32)	5,490	about 0.3 s
12:59:59 to 1:00:00	9,078	about 0.3 s

Most of the new-minute time goes to the 59 ticks that go dark at the top of the minute, which shows as a quick sweep around the ring. For comparison, the analog face in lab 05 takes up to 232 ms every second, because erasing its second hand also means redrawing the other hands.

The tick shapes use sines, cosines, and a scanline fill, which takes about 7 ms per tick. None of that changes, so the face computes each tick's pixels once at startup and replays them after that. It's a compute once, draw many times trade: 0.6 s at startup and 53 KB of RAM.

The Weather Clock

09-weather-clock.py shows the time in smaller seven-segment digits and the date. Below them are two columns, Today and Tomorrow, each with a weather icon, the high and low temperatures, and a word or two.

Where the forecast comes from

The forecast comes from Open-Meteo, a free weather service that needs no account and no API key. You ask for exactly the numbers you want, and it sends back only those. For two days of highs, lows, and weather codes the whole answer is about 450 bytes:

{"daily": {"time": ["2026-09-25", "2026-09-26"],
           "weather_code": [3, 63],
           "temperature_2m_max": [70.3, 61.0],
           "temperature_2m_min": [58.1, 56.8]}}

The Pico fetches and reads that in about a second. forecast.py does the fetching. To see the same answer from your computer, run:

curl "http://api.open-meteo.com/v1/forecast?latitude=44.98&longitude=-93.27&daily=weather_code,temperature_2m_max,temperature_2m_min&temperature_unit=fahrenheit&timezone=auto&forecast_days=2"

Set your own location with LATITUDE and LONGITUDE in config.py (the default is Minneapolis), and TEMPERATURE_UNIT to "fahrenheit" or "celsius".

Why not OpenWeatherMap?

The weather labs in the Learning MicroPython course use OpenWeatherMap. Its 5-day forecast also has sun, cloud, and rain conditions, but it needs an API key and sends 40 three-hour forecasts, about 16 KB. You would then work out each day's high and low yourself. Open-Meteo sends the daily high and low directly.

The icons

The weather_code is a WMO code, a numbering the World Meteorological Organization uses for weather. forecast.describe() turns it into one of five icons:

Icon	WMO codes	Words shown
Sunny	0, 1	Sunny
Partly cloudy	2	Pt cloudy
Cloudy	3, 45, 48	Cloudy, Fog
Rain	51-67, 80-82, 95-99	Drizzle, Rain, Frz rain, Showers, T-storms
Snow	71-77, 85, 86	Snow

Each icon is built from circles, polygons, and lines. Drawn straight to the glass, you would see it being built. So each icon is drawn first in RAM, in a 64×64 frame buffer (8 KB) using MicroPython's framebuf module and its filled ellipse() and poly(). It is then sent to the display in one blit_buffer() call, and the screen goes straight from the old icon to the new one.

One catch: framebuf stores each RGB565 pixel low byte first, and the GC9B72 wants the high byte first. Every color drawn into the frame buffer goes through swapped() to fix that. Without it, red comes out as a murky green.

How often it updates

The forecast refreshes at :00:30 and :30:30 every hour. The one just after midnight moves Tomorrow over to Today. If the WiFi or the service does not answer, the clock keeps showing the last forecast and tries again every 5 minutes. The clock stands still for the second or two a fetch takes, then catches up.

Measured on the Pico 2 W, a normal second takes 1.8 ms, and a new forecast takes about 190 ms to draw.

Stopwatch and Countdown Timer

Both tools use the three buttons the same way, so moving between them is easy. UP starts and stops, DOWN resets, and MODE does each tool's extra job. DOWN only resets when the tool is stopped or paused, so a bump can't wipe out a run. A line near the top of the screen always shows what the buttons do right now.

Button	Stopwatch (lab 10)	Timer (lab 11)
UP (GP14)	Start / stop	Start / pause. While setting: add one.
DOWN (GP15)	Reset, when stopped	Reset, when paused. While setting: take one away.
MODE (GP13)	Lap, while running	Set: minutes, then seconds, then done

The stopwatch

The time shows as MM:SS in large digits, with hundredths of a second in smaller ones, and a dot runs around the rim once a minute. Each MODE press while running records a lap, and the three most recent laps are listed below the time, newest on top in yellow. Once there are two laps, the fastest one turns green, and a line just under the digits shows the best and average lap times. The best time stays there even after the fastest lap has scrolled off the list.

A stopwatch never keeps time by adding a little each time around its loop, because the loop's speed changes whenever it draws something. It remembers when it started and asks the Pico's millisecond clock how long ago that was. Stopping adds the time so far to a running total, so the next start carries on from there.

The countdown timer

Press MODE to set the minutes, then the seconds, with UP and DOWN. Hold either one and the number keeps changing. Press MODE once more when done, then UP to start. The ring starts full and empties back toward 12 o'clock as time runs out, and the digits turn red for the last 10 seconds. At zero the display flashes 00:00 in red, the onboard LED flashes with it, and both keep going until any button is pressed.

The timer is a good first look at a state machine. What a button does depends on what the timer is doing: UP means "add one" while setting, "start" when ready, and "pause" while running. The program keeps one variable that says which of six states it is in, and handles every button press by checking that state first. The header of 11-countdown-timer.py has the whole machine drawn out.

Adding a buzzer

The alarm is silent unless you add a piezo buzzer. Wire its + leg to a free GPIO pin and its − leg to GND, then set BUZZER_PIN in config.py to that pin number. It will then beep in time with the flashing.

The watch parts module

The seven-segment digits and the seconds ring from lab 08, and the button handling from lab 07, are packaged in lib/watchparts.py so that any face can use them:

Part	What it does
`Digit`	A seven-segment digit of any size, repainting only the pieces that change
`TickRing`	60 ticks around the rim, each repainted only when its color changes
`TextLine`	A fixed-width line of text, repainting only the characters that change
`Button`	A push button with debounce, hold-to-repeat, short and long presses, and an interrupt that catches quick taps

Each display part remembers what it last drew, so showing the same thing again sends nothing at all.

One Watch, Five Modes

12-main-template.py turns the kit into one watch. Press MODE to step through five modes:

Weather → Analog → Digital → Stopwatch → Timer → back to Weather

It starts in Weather. A row of five dots at the bottom of the screen shows which mode you are in. On the analog face, the dots take the place of the 6 o'clock hour marker.

Modes are loaded only when needed

Each mode is its own module: mode_weather.py, mode_analog.py, mode_digital.py, mode_stopwatch.py, and mode_timer.py. Only the mode on the screen is in memory. When you press MODE, the template:

asks the current mode to stop(), and keeps whatever it hands back
removes that mode, and every module it brought in with it, from memory, then runs the garbage collector
imports the next mode and calls its start()

Measured on the Pico 2 W, 364–400 KB stays free in every mode, and it does not creep down as you switch. A switch takes 0.7–0.9 s from pressing MODE to the new mode fully drawn.

The four functions every mode has

That is all the template knows about a mode, so a sixth mode is just one more module like these:

Function	What it does
`start(display, up, down, saved)`	Draw the whole screen. `saved` is what `stop()` returned last time, or `None`.
`update(now)`	Called about every 10 ms. Read UP and DOWN, redraw only what changed.
`on_mode(kind)`	Optional. MODE was pressed, `SHORT` or `LONG`. Return `True` if the mode used the press itself.
`stop()`	Turn off anything that is on, and return a dict to keep for next time, or `None`.

A mode must also leave the strip where the dots go clear, and must not clear the whole screen except in start().

Modes keep running in the background

What stop() hands back is how a mode keeps going while you look at another one:

Stopwatch: a running stopwatch keeps running. Its time always comes from the Pico's millisecond clock, so it is still right when you come back.
Timer: a running timer keeps counting down. Its saved state includes a wake_at time, and when that moment comes the template switches straight to the timer for the alarm, whatever mode is showing.
Weather: the weather mode keeps its last forecast. If that forecast is less than 30 minutes old and from today, it is shown right away with no wait for WiFi.

The buttons in each mode

MODE now switches modes, so the stopwatch and timer use it differently than labs 10 and 11 do:

Mode	UP	DOWN	MODE
Stopwatch	Start / stop	Lap while running, reset while stopped	Next mode
Timer	Start / pause (+1 while setting)	Reset while paused (−1 while setting)	Next mode. Hold 1 s to set; while setting, next field.

While the timer is being set, or its alarm is going off, it keeps MODE for itself, so a press there can't switch modes by accident.

Short and long presses are told apart by Button.short_or_long() in lib/watchparts.py. A short press is reported when the button is let go, and a long press as soon as it has been held for a second. Each Button also uses a pin interrupt to catch quick taps. The analog face spends up to 232 ms each second drawing, and a weather fetch takes a second or two. A tap that goes down and up during that time would otherwise never be seen by the loop.

Making the Watch Start by Itself

MicroPython runs main.py from the Pico's filesystem at power-up. To turn the kit into a standalone watch, copy 12-main-template.py to the Pico as main.py for all five modes. Or copy just one face: 05-analog-watch-face.py, 08-digital-watch-face.py, or 09-weather-clock.py. With SYNC_WITH_WIFI = True either face sets its clock over WiFi at power-up and again at 3:00 AM every night. If WiFi is not available it keeps running on whatever time the clock already has.

Troubleshooting

Symptom	Likely cause
`mpremote: failed to access ... (it may be in use by another program)`	Thonny is still connected. Quit it or click Stop/Disconnect.
`ImportError: no module named 'gc9b72'`	The `lib/` files did not upload. Run `upload-code.sh` again.
Screen stays black	Check the five signal wires (SCL, SDA, RST, DC, CS). Swapped SCL and SDA is the most common mistake. Check that VCC is on 3V3.
The LED does not blink in lab 00	You flashed the plain `RPI_PICO2` firmware. Use `RPI_PICO2_W`.
The clock shows the wrong time on battery	The Pico has no clock battery. Thonny sets the clock while it is connected. Use lab 04, or `SYNC_WITH_WIFI` in lab 05.
Time is off by one hour	Check `TIMEZONE_HOURS` and `USE_US_DST` in `config.py`.
The probe says your network was not found	Check the spelling in `secrets.py`, and that the network is 2.4 GHz.
The weather clock shows `--` for every temperature	It has not received a forecast yet. Check the Thonny shell for `Forecast failed`. It tries again every 5 minutes.
A button does nothing	An unwired button reads "not pressed" forever. Use lab 06 to test each one.
